Description:
ZX-685 Mechanical Seal
For big compressors and industrial pumps
Replacing the mechanical seal of Burgmann MFL85N
Technical Parameter:
Temperature: -20℃ to +200℃
Pressure: ≤2.1MPa
Speeds: ≤23m/s
Materials:
Stationary Ring：TC, Silicon Carbide
Rotary Ring：Carbon ,Silicon Carbide,TC
Secondary Seal：NBR,EPDM,Viton
Bellows：Steel Spring and Metal Parts：Steel
Applications:
Oil, light hydrocarbon, week acids
aromatic Hydrocarbon,organic solvents, ammonia
